M16 Industrial 5 Pin Circular Connector Sizes Outdoor Waterproof Plug Socket Sale

  • 1
  • 2
  • 3

Brand Name : Ulinkcon

Model Number : M16

Certification : CE/Rohs/TUV/UL

Place of Origin : China

MOQ : Negotiation

Price : Negotiation

Payment Terms : T/T,D/A,D/P,MoneyGram,L/C

Supply Ability : 100000 pairs each month

Delivery Time : 3~6 working days

Packaging Details : High Quality export carton

Number of Pins : 5Pin

Current : 8A max. for Power

Rated voltage : 125V

Waterproof Rating : IP67

operating temperature : -40℃~+105℃

Contact Material : Brass Gold-Plated

Contact Now

M16 DC Waterproof Connector Wire To Board 5 Pin Power Quick Lock Connector
Quick Details
  • 5-Pin Power-Specific Structure
    5-pin layout supports both power supply and signal transmission, compatible with multi-channel DC power output for wide application.

  • DC-Specific Waterproof Connection
    Professional DC power solution with excellent insulation, anti-leakage and short-circuit protection for safer use in humid environments.

  • Quick-Lock Threadless Self-Locking System
    One-press quick locking without thread rotation, efficient plug-and-play, shockproof and anti-loose for long-term reliability.

  • IP67 High Protection Level
    Fully sealed waterproof and dustproof, suitable for harsh outdoor and industrial environments, stable and reliable under long-term use.

  • High-Quality Conductive & Insulating Materials
    High-conductivity copper alloy contacts, heat-resistant and flame-retardant housing, low contact resistance, safe and durable.
Key Features
  • Push-lock quick release system
  • Multiple core options: 2Pin, 3Pin, 4Pin, 5Pin, 2+4Pin, 7Pin, 8Pin
  • Field assembly version supports both wire-to-wire and wire-to-board connections
  • High current rating up to 8A for continuous operation
  • Cable assembly service available for custom requirements
  • OEM/ODM services supported
Electrical Parameters
Number of Poles 5Pin waterproof connector
Current Rating 8A max
Voltage Rating 125VAC max
Durability Voltage 500VAC @ 60 s
Technical Parameters
Contact Resistance 10 mΩ max
Insulation Structure 500 MΩ at 500VDC
Operating Temperature -40°C ~ +105°C
IP Class IP67 (1m / 30min)
Mold Material PA66
Contact/Terminal Material Gold Plated Brass
Seal Material Silicone
Application Industries
  • Communications equipment
  • Product coding machines
  • Inventory product coding systems
  • Inkjet systems
  • Solar power systems
  • Industrial inkjet equipment
  • Electric power equipment
  • Laboratory forensic & pathology equipment
  • Heavy machinery
Production Dimension
M16 Industrial 5 Pin Circular Connector Sizes Outdoor Waterproof Plug Socket Sale
Professional Manufacturer
M16 Industrial 5 Pin Circular Connector Sizes Outdoor Waterproof Plug Socket Sale
Frequently Asked Questions
Q1: Are you a factory or trading company?
A1: We are a factory. Located in Ulinkcon Industrial Park, Bao'an District, Shenzhen, China
Q2: How many materials you can provide?
A2: There are different materials available for connectors and cables. We typically use PVC/Nylon material for connectors, and PVC/Rubber/Silicone materials for cables. We can also select materials according to your specific requirements.
Q3: Do you accept other payment currencies besides USD?
A3: Our default currency is USD, but we can also accept EUR, GBP, or other major currencies. Please confirm the exchange rate with our sales team when placing the order.
